5Functions set with parameters
Automatic return setting after jog feed at pause 5-370
P1
P2
P1
P2
RETPATH=1 or 2 RETPATH=0
Move to target
position
Jog feed
Interrupt here
Resume the
automatic
execution
Jog feed
Move to target
position
Resume the
automatic
execution
Interrupt here
