3Explanation of operation methods
Ooperation of operating screen 3-62
3.12.2 Test operation
(1) Select the test operation
1) Press the [2] key in the menu screen, and display the operation menu screen.
2) Press the [2] key, and display the test operation screen.
The program name, execution step number, and operating mode is displayed.
3) When the function key ([F2]) corresponding to "CSTOP" is pressed during program execution, it is change
to the cycle mode of operation. The "cycle" is displayed after the mode and the [END] button of the
operation panel blinks. Finish operation after executing the last line of the End command or the program.
4) Press the function key corresponding to "Close", and return to the operation menu screen.
<MENU>
1.FILE/EDIT 2.RUN
3.PARAM. 4.ORIGIN/BRK
5.SET/INIT.
CLOSE
123
<RUN>
1.CHECK 2.TEST RUN
CLOSE
123
<TEST RUN>
1 Mov P1
PROG.NAME: 1 STEP: 1
MODE: CONT.
CLOSE
123
⇒
CSTOP
<RUN>
1.CHECK 2.TEST RUN
CLOSE
123
<TEST RUN>
1 Mov P1
PROG.NAME: 1 STEP: 1
MODE: CYCLE
CLOSE
123
⇒
CSTOP
<TEST RUN>
1 Mov P1
PROG.NAME: 1 STEP: 1
MODE: CONT.
CLOSE
123
⇒
CSTOP
<RUN>
1.CHECK 2.TEST RUN
CLOSE
123
<TEST RUN>
1 Mov P1
PROG.NAME: 1 STEP: 1
MODE: CONT.
CLOSE
123
⇒
CSTOP
◇◆◇ If execution of the program is stopped, it will become the continuation mode of operation. ◇◆◇
If the [STOP] key is pressed in the cycle mode of operation and execution of the program is stopped, it
changes to the continuation mode of operation. If it continues execution of the program by the cycle mode of
operation, please press the [F4] key again after pushing the [START] button. (It also becomes the cycle
mode of operation to push the [END] button of the controller)
