3-71
Operating the monitor screen
3Explanation of operation methods
(5) Variable monitor
It is the function to display or change the details of the variable currently used by the program.
1) Press the [5] key in the monitor menu screen, and display the variable monitor screen.
2) Specify the target program of the monitor with the slot number.
Press the function key corresponding to "SLOT", and input the slot number.
Set up "1", if the multitasking function is not being used.
3) "Display the slot number and the program name after "slot:."
Press the function key corresponding to the "Name", and input the variable name to monitor.
4) Display the value of the numeric variable M1 on the screen.
The variable which will be monitored if the cursor is moved to the line which is vacant in the arrow key and
operation of the above 3 is repeated can be added. The variable which can be monitored simultaneously is
to the three pieces.
<MONITOR>　　 　
1.INPUT
2.OUTPUT
3.INPUT REG. 4.OUTPUT REG.
5.VARIABLE 6.ERROR LOG
CLOSE
　 123
<VARIABLE>
SLOT : 1 TEST
=
=
=
CLOSE
123
VALUE
SLOT
NAME
<VARIABLE>
SLOT ( 1_ )
CLOSE
123
<VARIABLE>
SLOT : 1 TEST
=
=
=
CLOSE
123
VALUE
SLOT
NAME
<VARIABLE>
SLOT : 1 5
=
=
=
CLOSE
123
VALUE
SLOT
NAME
<VARIABLE>
NAME ( M1_ )
CLOSE
123
<VARIABLE>
SLOT : 1 5
M1 =＋1
=
=
CLOSE
123
VALUE
SLOT
NAME
<VARIABLE>
SLOT : 1 5
M1 =＋1
P1 =(＋595.40､＋0.00､＋829.)
C1 =
CLOSE
123
VALUE
SLOT
NAME
Add the variable to monitor.
