6.6 Intelligent Function Module Switch Setting
6
PRE-OPERATIONAL PROCEDURES AND SETTINGS
2) Communication speed setting
*1 *2
* 1 Total communication speed for 2 channels can be set within 115200bps.
* 2 Do not set any value or set “07
H” (Initial value) in the communication speed setting for an unused
channel.
(c) CH1, 2 station No. setting (Switch 5)
Set slave station No. of the QJ71MB91.
For the master function, set 00
H.
For a slave station number, specify a value within the range shown below.
* 1 Setting a value outside the range shown in the table results in a switch error.
Table6.9 Communication speed setting
Communication
speed
Bit position
Communication
speed
Bit position
b15 to b8 b15 to b8
300 bps 00H 14400 bps 06H
600 bps 01H 19200 bps 07H
1200 bps 02H 28800 bps 08H
2400 bps 03H 38400 bps 09H
4800 bps 04H 57600 bps 0AH
9600 bps 05H 115200 bps 0BH
Figure 6.22 CH1, 2 station No. setting structure
Table6.10 Station No. setting
Set value
*1
Description
1H to F7H Sets a slave station No. (1 to 247).
b0b1b2b3b4b5b6b7b8b9
b15 b14 b13 b12 b11 b10
CH2 side Station No. CH1 side Station No.
