7 - 13
7.3 MODBUS(R) Device Assignment Parameter
7.3.1 MODBUS(R) device assignment to the programmable controller CPU device memory
7
PARAMETER SETTING
7.3.1 MODBUS(R) device assignment to the programmable controller CPU
device memory
(1) MODBUS device size
The MODBUS devices available for the QJ71MB91 are shown below.
* 1 The availability of Extended file register read/write depends on that of the file register (ZR) read/
write to the programmable controller CPU.
For example, if the file register (ZR) is stored on a Flash card, the extended file register is read only
because the file register (ZR) is read only.
User's Manual (Function Explanation, Program Fundamentals) for the CPU module used
* 2 The maximum access points and maximum file number of the extended file register depend on the
file register (ZR) assignment size of the programmable controller CPU.
User's Manual (Function Explanation, Program Fundamentals) for the CPU module used
Remark
Refer to the following for assignment of the extended file register and the
programmable controller CPU file register (ZR).
Section 7.3.2
Table7.5 MODBUS device size
MODBUS device type
Read/Write Access points
MODBUS device number
Coil Read/Write 65536 points 000001 to 065536
Input Read 65536 points 100001 to 165536
Input register Read 65536 points 300001 to 365536
Holding register Read/Write 65536 points 400001 to 465536
Extended file register (*1)
4184064 points
*2
File No.: 0 to 418
*2
600000 to 609999
To Next Page
