4 - 33
4.11 Diagnostics (FC: 08)
4.11.6 Clear counters and diagnostic register (sub-function code: 10)
4
MODBUS(R) STANDARD FUNCTIONS
4.11.6 Clear counters and diagnostic register (sub-function code: 10)
Clears counters (e.g. message count).
Also, clears the diagnostic register and the error of the channel where the request
message has been received.
The following counters will be cleared.( Section 11.3)
Bus message count
Bus communication error count
Exception error count
Slave message count
Slave no-response count
Slave NAK count
Slave busy count
Character overrun error count
Communications event count ( Section 4.12)
The following diagnostic resisters will be cleared.
CH1/2 side detailed LED status storage area of the buffer memory (address:
0006
H
/0007
H
)
*1
CH1/2 side error response code storage area of the buffer memory (address:
0002
H
/0004
H
)
*1
* 1 Clears only the receiving channel side area.
