11 - 47
11.5 Turning Off the ERR. LED
11.5.3 Turning off the ERR. LED by request message from the master
11
TROUBLESHOOTING
11.5.3 Turning off the ERR. LED by request message from the master
When the QJ71MB91 is a slave, the ERR.LED can be turned off by a request message
from the master.
The following explains how to turn off the ERR. LED by issuing a request message from
the master.
(1) Procedure for turning off the ERR. LED
Send a request message containing the following to the slave (QJ71MB91) from the
master after removing possible error causes.
Restart communications option ( Section 4.11.2)
Clear Counters and Diagnostic Register ( Section 4.11.6)
To Next Page
