11 - 13
11.2 Checking QJ71MB91 Status
11
TROUBLESHOOTING
2) Display data
* 1 The alphabet at the end of the Product information indicates the function version of the module.
The function version of the QJ71MB91 is available from B.
Example: The end character of "B" indicates that the module is of function version B.
* 2 Display of the contents and disposal is available on GX Developer Version 8.29F or later.
Table11.5 Displayed data of Module's Detailed Information
Item Description
Module
Module Name Displays the model name of the target module.
I/O Address Displays the head I/O number of the target module.
Implementation
Position
Displays the slot position where the module is mounted.
Product information
Displays the serial No. and function version of the target module.
*1
Module information
Module access
Displays Enable when the Module READY (X0) is on and the Watch dog timer error (X1F)
is off.
Status of I/O Address
Verify
Displays whether or not the module parameterized by the user matches the mounted
module.
Error Display
Present Error
Displays the error code of the latest error. ( Section 11.4)
Error display
Displays the latest 16 error codes that are stored in the Error log (address: 0CFE
H
to
0DFF
H
) of the buffer memory.
Error contents
- Disposal
Contents
Displays the error contents and disposal for the error code selected in Error Display.
*2
Disposal
