Mitsubishi QJ71MB91 - X;Y Monitor;Test

8
UTILITY PACKAGE (GX Configurator-MB)
8.6 Monitor/Test
8.6.1 X/Y Monitor/test
8 - 29
1
OVERVIEW
2
SYSTEM CONFIGURATION
3
SPECIFICATIONS
4
MODBUS(R) STANDARD FUNCTIONS
5
FUNCTION
6
PRE-OPERATIONAL PROCEDURES AND SETTINGS
7
PARAMETER SETTING
8
UTILITY PACKAGE (GX Configurator-MB)
8.6.1 X/Y Monitor/test
[Monitor/Test Purpose]
Monitor I/O signals and performs tests on output signals.
[Operating procedure]
Monitor/Test screen
[Monitor/Test Screen]
Figure 8.13 X/Y Monitor/test screen
X/Y Monitor/test
