Mitsubishi QJ71MB91 User Manual

8 - 30
8.6 Monitor/Test
8.6.1 X/Y Monitor/test
8
UTILITY PACKAGE (GX Configurator-MB)
[Monitor/Test Items]
(1) X: Input signals
(2) Y: Output signals
To perform a test on output signals, select any item in the Setting value column and
click the button.
Table8.11 Setting items on the X/Y Monitor/test screen (Input signals)
Monitor/test item Buffer memory address Reference
X00: Module READY -
Section 9.1.1
X04: CH1 Automatic communication parameter setting, normally completed -
X05: CH1 Automatic communication parameter setting, error completed -
X06: CH1 Automatic communication operation status -
X07: CH1 Automatic communication error status -
X08: MODBUS(R) device assignment parameter setting, normally completed -
Section 9.1.2
X09: MODBUS(R) device assignment parameter setting, error completed -
X0A: MODBUS(R) device assignment parameter setting existence -
X0C: CH2 Automatic communication parameter setting, normally completed -
Section 9.1.1
X0D: CH2 Automatic communication parameter setting, error completed -
X0E: CH2 Automatic communication operation status -
X0F: CH2 Automatic communication error status -
X1B: CH common/CH1 error -
Section 11.5
X1C: CH2 error -
X1F: Watch dog timer error --
Table8.12 Setting items on the X/Y Monitor/test screen (Output signals)
Monitor/test Item Buffer memory address Reference
Y04: CH1 Automatic communication parameter setting request/Automatic communication
start request
-
Section 9.1.1
Y06: CH1 Automatic communication stop request -
Y08: MODBUS(R) device assignment parameter setting request - Section 9.1.2
Y0C: CH2 Automatic communication parameter setting request/Automatic communication
start request
-
Section 9.1.1
Y0E: CH2 Automatic communication stop request -
Y1B: CH common/CH1 error clear request -
Section 11.5
Y1C: CH2 error clear request -
Execute test
