8 - 2
8.2 Installing and Uninstalling the Utility Package
8.2.1 Handling precautions
8
UTILITY PACKAGE (GX Configurator-MB)
8.2 Installing and Uninstalling the Utility Package
For how to install or uninstall the utility package, refer to "Method of installing the
MELSOFT Series" included in the utility package.
8.2.1 Handling precautions
The following explains the precautions on using the GX Configurator-MB.
(1) For safety
Since GX Configurator-MB is add-in software for GX Developer, read "Safety
Precautions" and the basic operating procedures in the GX Developer Operating
Manual.
(2) About installation
GX Configurator-MB is add-in software for GX Developer Version 4 or later.
Therefore, GX Configurator-MB must be installed on the personal computer that has
already GX Developer Version 4 or later installed.
(3) Screen error of Intelligent function module utility
Insufficient system resource may cause the screen to be displayed inappropriately
while using the Intelligent function module utility.
If this occurs, close the Intelligent function module utility, GX Developer (program,
comments, etc.), and other applications, and then start GX Developer and Intelligent
function module utility again.
(4) To start the Intelligent function module utility
(a) PLC series set on GX Developer
In GX Developer, select "QCPU (Q mode)" for PLC series and specify a project.
If any PLC series other than "QCPU (Q mode)" is selected, or if no project is
specified, the Intelligent function module utility will not start.
(b) Activating multiple sets of utility software
Multiple Intelligent function module utilities can be started.
However, [Open parameters] and [Save parameters] operations under [Intelligent
function module parameter] are allowed for one Intelligent function module utility
only.
Only the [Monitor/test] operation is allowed for the other utilities.
To Next Page
