(b) Mounting to a MELSECNET/H remote I/O station
The table below shows the network modules and base units applicable to the
QJ71MB91 and quantities for each network module model.
Depending on the combination with other modules or the number of mounted
modules, power supply capacity may be insufficient.
Pay attention to the power supply capacity before mounting modules, and if the
power supply capacity is insufficient, change the combination of the modules.
: Applicable, : N/A
* 1 Limited within the range of I/O points for the network module.
* 2 Can be installed to any I/O slot of a base unit.
Remark
The Basic model QCPU or C Controller module cannot create the MELSECNET/
H remote I/O network.
Table2.1 Applicable CPU modules and base units, and No. of modules (Continued)
Applicable CPU module
No. of modules
*1
Base unit
*2
CPU type CPU model
Main base unit
*1
Extension base unit
Programmable
controller CPU
Universal model
QCPU
Q03UDECPU
Up to 64
Q04UDEHCPU
Q06UDEHCPU
Q10UDEHCPU
Q13UDEHCPU
Q20UDEHCPU
Q26UDEHCPU
Safety CPU QS001CPU N/A
*3
C Controller module
Q06CCPU-V
N/A
Q06CCPU-V-B
Table2.2 Mountable network modules, No. of mountable modules, and mountable base unit
Applicable network module
No. of
modules
*1
Base unit
*2
Main base unit of
remote I/O station
Extension base unit of
remote I/O station
QJ72LP25-25
Up to 64
QJ72LP25G
QJ72LP25GE
QJ72BR15
To Next Page
