TROUBLESHOOTING
11.2 Checking QJ71MB91 Status
11 - 16
9
PROGRAMMING
10
DEDICATED INSTRUCTIONS
11
TROUBLESHOOTINGAPPENDICESINDEX
(H/W SW Information)
The intelligent function module switch status of the QJ71MB91 is displayed.
The displayed values correspond to those in the intelligent function module switch setting
status (address:0C00
H to 0C04H) of the buffer memory.
(4) Input signals (X)
The status of the QJ71MB91 can be confirmed by the input signals shown below.
(5) Buffer memory
The QJ71MB91 status can be confirmed with the buffer memory.
• Detailed LED status ( This section(3)(b))
• Error confirmation ( Section 11.4)
Table11.7 Display of H/W SW information
No.
Status signal
name
Description Reference
1 CH1 MODE Switch 1: CH1 operation mode setting status
Section 6.6
2 1 CONFIG Switch 2: CH1 transmission setting status
3 CH2 MODE Switch 3: CH2 operation mode setting status
4 2 CONFIG Switch 4: CH2 transmission setting status
5 ST NO. Switch 5: CH1/CH2 Station No. setting status
Table11.8 Input signals for status check
Input
signal
Description Error type Reference
X1B CH common/CH1 error
General
Section 11.1
X1C CH2 error
X1F Watch dog timer error H / W error
X5
CH1 Automatic communication parameter setting,
error completed
Automatic
communication
function
XD
CH2 Automatic communication parameter setting,
error completed
X7 CH1 Automatic communication error status
XF CH2 Automatic communication error status
X9
MODBUS device assignment parameter setting,
error completed
MODBUS device
assignment function
