(8) Error log
Up to 32 latest errors are stored in the Error log area as an error history.
(a) Number of errors occurred
The number of errors entered to the error log is stored.
If 65536 or more errors have occurred, the count stops at FFFF
H
(65535).
(b) Error log write pointer
The number of the latest error log is stored.
0 : No error (No error log entry)
1 to 32 : Error log number where the latest error log was entered
Table11.13 Configuration of the Error log area
Error log area name Address
Number of errors occurred 0CFE
H
(3326)
Error log write pointer 0CFF
H
(3327)
Error log 1
Detailed error code 0D00
H
(3328)
Exception code 0D01
H
(3329)
Function code 0D02
H
(3330)
CH 0D03
H
(3331)
Station No.
0D04
H
(3332)
Function
0D07
H
(3335)
Error logs 2 to 32 (same as Error log 1)
0D08
H
to 0DFF
H
(3336 to 3583)
