APPENDICES
Appendix 3 Processing Time
App - 11
9
PROGRAMMING
10
DEDICATED INSTRUCTIONS
11
TROUBLESHOOTING
APPENDICES
INDEX
* 1 Request message transmission time [ms]:
Ttq = Request message size [bytes] Bits of 1 character / Transmission speed [bps] 1000
* 2 Response message transmission time [ms]:
Ttr = Response message size [bytes] Bits of 1 character / Transmission speed [bps] 1000
* 3 1 character time = Bits of 1 character / Transmission speed [bps] 1000
TableApp.10 Processing time calculation items used when mounted with a programmable
controller CPU (Continued)
Item Description Unit
n1
Any of the following values are applied depending on the
function code and assignment status.
-
Function code
When programmable
controller CPU device is
assigned
When buffer
memory is
assigned
01 1 0
02 1 0
03 1 0
04 1 0
05 1 0
06 1 0
07 1 0
08 0 0
11 0 0
12 0 0
15 1 0
16 1 0
17 0 0
20 1 0
21 1 0
22 2 0
23 2 0
n2
Any of the following values are applied depending on the
function code and assignment status.
-
Function code
When programmable
controller CPU device is
assigned
When buffer
memory is
assigned
Normal case Worst case
01 1 2 0
02 1 2 0
03 1 2 0
04 1 2 0
05 1 2 0
06 1 2 0
07 1 2 0
08 0 0 0
11 0 0 0
12 0 0 0
15 1 2 0
16 1 2 0
17 0 0 0
20 1 2 0
21 1 2 0
22 2 4 0
23 2 4 0
