APPENDICES
Appendix 4 External Dimensions
App - 13
9
PROGRAMMING
10
DEDICATED
INSTRUCTIONS
11
TROUBLESHOOTING
APPENDICES
INDEX
Appendix 4 External Dimensions
* 1 R1 (Bending radius near terminal block) : Outer cable diameter 4
* 2 R2 (Bending radius near connector) : Outer cable diameter 4
* 3 r1 (Bending radius near crimp contact) : Connectable as long as not bended extremely
FigureApp.3 External dimensions
90 (3.54)
4.5 (0.18)
27.4 (1.08)
Unit
:
mm (inch)
98 (3.86)
R1
(*1)
R2
(*2)
r1
(*3)
Cable diameter
4+10
23 (0.91)
4
(0.16)
To Next Page
