NICE7000 User Manual 7 Description of Function Codes
- 189 -
Note that the latest CTB-D has nine input terminals, but the wiring is not affected when the
NICE7000 is connected to the CTB of the earlier version.
Function
Code
Parameter Name Setting Range Default Unit Property
FL-01
HCB-B:JP1 input
0: Invalid
1: Light-load signal
2: Half-load signal
3: Door 2 selection
4: Door 2 restricted
5: Door 1 safety edge
6: Door 2 safety edge
7: Single/Double door selection
8: Fire emergency oor switchover
9: Fire emergency start signal
0 - ★
FL-02
HCB-B:JP2 input
0 - ★
FL-03
HCB-B:JP3 input
0 - ★
FL-04
HCB-B:JP4 input
0 - ★
FL-05
HCB-B:JP5 input
0 - ★
FL-06
HCB-B:JP6 input
0 - ★
These parameters are used to set the functions of input terminals on the HCB-B board.
Function
Code
Parameter Name Setting Range Default Unit Property
FL-07
HCB-B:A1 output
0: Invalid
1: Fault output
2: Non-door zone stop output
3: Non-service state output
4: Fire emergency output
5: Power failure emergency output
6: Door lock valid
7: Night output signal
8: Fire emergency indicator
9: Fire emergency tone
0 - ★
FL-08
HCB-B:A2 output
0 - ★
FL-09
HCB-B:B1 output
0 - ★
FL-10
HCB-B:B2 output
0 - ★
FL-11
HCB-B:C1 output
0 - ★
FL-12
HCB-B:C2 output
0 - ★
FL-13
HCB-B:C3 output
0 - ★
FL-14
HCB-B:C4 output
0 - ★
FL-15
HCB-B:C5 output
0 - ★
FL-16
HCB-B:C6 output
0 - ★
These parameters are used to set the functions of output terminals on the HCB-B board.
