Moog G392-004 User Manual

MSDServoDrive AC-AC Operation Manual
moog
28
Id. no.:CA65642-001 Date:03/2012
to the glossaryto the table of contents
Servo
drive
Device connected load
1)
[kVA]
Maximum
cable cross-
section
2)
of
terminal [mm²]
Specified mains
fuse, duty class
gG [A]
With mains
choke (4%u
K
)
Without
mains choke
G392-004A 1.6 2.2 4 1xmaximum 16
G392-004 2.8 4.0 4 3xmaximum 10
G392-006 4.2 6.0 4 3xmaximum 16
G392-008 5.9 8.3 4 3xmaximum 20
G392- 012 8.8 12.5 4 3xmaximum 25
G392-016/
G395-016
11.1 15.0 16 3xmaximum 32
G392-020/
G395-020
13.9 18.7 16 3xmaximum 40
G392-024/
G395-024
16.6 22.5 16 3xmaximum 50
G392-032/
G395-032
22.2 30.0 16 3xmaximum 63
With mains
choke (2%u
K
)
1) With 3x400V mains voltage
2) The minimum cross-section of the power supply cable depends on local regulations and conditions, as well as on the rated
AC current of the servo drive.
Table 3.7 Connected load an mains fuse
Servo
drive
Device connected load
1)
[kVA]
Maximum
cable cross-
section
2)
of
terminal [mm²]
Specified mains
fuse, duty class
gG [A]
With mains
choke (4%u
K
)
Without
mains choke
G392-045/
G395-053
31
For devices of
sizes Size5 to
Size7 a mains
choke is manda-
tory.
25 3xmaximum 63
G392-060/
G395-070
42 25 3xmaximum 80
G392-072/
G395-084
50 25
3xmaximum 100
G392-090/
G395 -110
62 50 3xmaximum 125
G392-110 /
G395-143
76 50 3xmaximum 160
G392-143/
G395-170
99 95 3xmaximum 200
G392-170/
G395-210
118 95 3xmaximum 224
G395-250 173
Connection via
screwed on ring
terminal ends.
3xmaximum 300
G395-325 225 3xmaximum 400
G395-450 310 3xmaximum 500
1) With 3x400V mains voltage
2) The minimum cross-section of the power supply cable depends on local regulations and conditions, as well as on the rated
AC current of the servo drive.
Table 3.7 Connected load an mains fuse
