Rating plate
The rating plate on MSDServoDrives informs about the serial number, from which you
can read the manufacturing date by using the following key. The location of the rating
plate on your MSDServoDriveAC-AC can be found from page 18 onwards.
Model:: G392-030-000-002
In: 230 V AC 3ph, 50/60 Hz
4,0 A
0-230 V AC 3ph, 0-400 Hz
3,0 A
Out:
MOOG
D-71034 Böblingen
www .moog.com/industrial
Made in Germany
S/N:D116605 Rev. A
ID : JJWWxxxxx
Year of production
Week of production
Fig 0.3 Rating plate hardware MSDServoDriveAC-AC Single-Axis System
Scope of supply
The scope of supply includes:
• MSDServoDriveAC-AC drive unit
• Terminal accessory pack for control and power terminals
(depending on device rated power and variant)
• Set of grommets (on devices with liquid cooling)
• Product DVD
Pictograms
Pictograms as described in the following table are used in this operation manual for
better orientation. The meaning of the corresponding pictogram is always correct, even
if it is placed e.g. next to a terminal diagram without any accompanying text.
Warning symbols (see also section1.1)
!
ATTENTION! Misoperation may cause damage to or malfunction of the
drive.
DANGER CAUSED BY HIGH VOLTAGE!
Improper behaviour may cause danger to human life.
DANGER FROM ROTATING PARTS!
The drive may automatically start to run.
Notes & supportive action
NOTE: useful information or reference to other documents
1.
STEP: Processing step within a multi-action sequence
