Chapter 8 Disassembly/Reassembly Procedures
This chapter provides detailed procedures for disassembling/reassembling and ensuring
submergibility of the APX 5000/ APX 6000/ APX 6000Li (R) radios. When performing these
procedures, refer to “Chapter 10: Exploded Views and Parts Lists” on page 1:10-1 and the diagrams
that accompany the text. Items in parentheses ( ) throughout this chapter refer to item numbers in the
exploded view diagrams and their associated parts lists.
This chapter also has procedures for removing and installing the APX 5000/ APX 6000/ APX 6000Li
radio’s standard accessories and changing the Volume and Frequency Knobs.
8.1 Exploded View (Main Subassemblies)
This section contains the APX 5000/ APX 6000/ APX 6000Li radio partially exploded views.
NOTES:
• Refer to Figure 8-1 on page 1:8-2, the Partial Exploded View, and Table 8-1 on page 1:8-5, the
Partial Exploded View Parts List.
• Letters in parentheses ( ) refer to item letters in Figure 8-1 on page 1:8-2 and
Table 8-1 on page 1:8-5.
When servicing electronics, always ensure that you are
properly grounded with antistatic grounding system approved
for electronics handling.
