Motorola APX 5000 User Manual

Sec 1: xiv Specifications for APX 5000 7–800 MHz Radios
Specifications for APX 5000 7–800 MHz Radios
All specifications are per Telecommunications Industries Association TIA-603 unless otherwise
noted.
GENERAL RECEIVER TRANSMITTER
Temperature Range:
Operating: -30°C to +60°C
Storage: -40°C to +85°C
Power Supply:
Nickel-Metal-Hydride Battery (NiMH)
or Lithium-Ion Battery (Li-Ion)
Battery Voltage:
Nominal: 7.5 Vdc
Range: 6 to 9 Vdc
Transmit Current Drain (Typical):
700 MHz: 1410 mA
800 MHz: 1696 mA
Receive Current Drain (Rated Audio): 250 mA
Standby Current Drain: 142 mA
Recommended Battery:
Li-Ion (Slim): PMN4403_
or Li-Ion: NNTN7038_
or Li-Ion Ultra High Cap: NNTN7034_
or Li-Ion Ultra High Cap and FM: NNTN7033_
*
or NiMH: NNTN7037_
or NiMH Ruggedized: NNTN7573_
or NiMH FM (Factory Mutual): NNTN7036_
*
or Li-Ion Ruggedized and FM: NNTN8092_
*
or NiMH Ruggedized and FM:
NNTN7035_
*
* FM Intrinsically Safe.
Dimensions (H x W x D):
Without Battery (Radio Only):
H = 5.50" (139.7 mm)
W
1
= 2.98" (75.7 mm) / 2.37" (60.2 mm)
D
2
= 1.60" (40.5 mm) / 1.37" (34.7 mm)
With Slim Li-Ion Battery:
H = 5.76" (146.3 mm)
W
1
= 2.98" (75.7 mm) / 2.37" (60.2 mm)
D
2
= 1.65" (41.8 mm) / 1.37" (34.7 mm)
With NiMH Battery:
H = 7.76" (197.1 mm)
W
1
= 2.98" (75.7 mm) / 2.37" (60.2 mm)
D
2
= 1.65" (41.8 mm) / 1.37" (34.7 mm)
Note:
H = Height; W = Width; D = Depth
1 = (Width @ Top) / (Width @ PTT)
2 = (Depth @ Bottom) / (Depth @ PTT)
Weight: (w/o Antenna):
Less Battery: 10.7 oz (303 g)
With Li-Ion Slim: 15.7 oz (445 g)
With Li-Ion Ultra High Cap: 21.1 oz (559 g)
With NiMH: 22.3 oz (631 g)
Frequency Range:
700 MHz: 764–776 MHz
800 MHz: 851–870 MHz
Bandwidth:
700 MHz: 12 MHz
800 MHz: 19 MHz
Analog Sensitivity (typical)
(12 dB SINAD): 0.25 µV
Digital Sensitivity (typical)
(1% BER): 0.375 µV
(5% BER): 0.24 µV
Intermodulation (typical): -80.05 dB
Selectivity
(typical):
(25 kHz Channel): -75.87 dB
(12.5 kHz Channel): -65.58 dB
Spurious Rejection (typical): -82.16 dB
Frequency Stability
(-30+60°C; 25°C reference): ±0.000086%
Rated Audio:
Internal Speaker: 500 mW
External Speaker: 500 mW
FM Hum and Noise (typical):
25 kHz -54 dB
12.5 kHz -47.92 dB
Distortion (typical): 1.74 %
Channel Spacing: 12.5/25 kHz
Frequency Range:
700 MHz: 764–776; 794–806 MHz
800 MHz: 806–825; 851–870 MHz
RF Power:
700 MHz: 1–2.7 Watts
800 MHz: 1–3.0 Watts
Frequency Stability (typical)
(-30 to +60°C; 25°C ref.):
700 MHz: ±0.000080%
800 MHz: ±0.000080%
Emission (typical conducted): -75 dBc
FM Hum and Noise (typical)
(Companion Receiver): 25 kHz -47 dB
12.5 kHz -45 dB
Distortion (typical): 2%
Modulation Limiting: 25 kHz chnls ±5 kHz
20 kHz chnls ±4 kHz
12.5 kHz chnls ±2.5 kHz
ACPR (typical): 25 kHz -72 dBc
12.5 kHz -66 dBc
Emissions Designators:
11K0F3E, 16K0F3E, 8K10F1D, 8K10F1E,
8K10F1W, 20K0F1E
Specifications subject to change without notice.

Motorola APX 5000 Specifications

General

Brand	Motorola
Model	APX 5000
Category	Two-Way Radio
Language	English
