Exploded Views and Parts Lists: APX 5000/ APX 6000/ APX 6000Li Dual Display (Full Keypad) Exploded View Parts List Sec 1: 10-3
10.2 APX 5000/ APX 6000/ APX 6000Li Dual Display
(Full Keypad) Exploded View Parts List
NOTE:
1. Kit NHN7015_ includes Items #15, 21, 22, 24–32 and 43. When purchasing this kit, need to purchase item 23
(qty. 2) together.
2. When purchasing item 21, need to purchase item 23 (qty. 2) together.
Item
No.
Motorola Part
Number
Description
1 NHN7024_
NHN7068_
NHN7069_
NHN7081_
Assy, Front Housing, Dual Display, M3,(Full Keypad)
Assy, Front Housing, Dual Display, M3 Black, Hebrew (Full Keypad)
Assy, Front Housing, Dual Display, M3 Black, Cyrillic (Full Keypad)
Assy, Front Housing, Dual Display, M3 Black, Arabic (Full Keypad)
2 33009265001 Medallion
3 NHN7013_ Assembly, Back Chassis, Dual Display
4 32009357001 Boot, Dataside Mic
5 3275002C03 Mic Membrane
6 35009312002 Mic Mesh
7 61009283002 Lens, Front Display
8 NHN7020_ Display, Front
9 NUD7120_
NUE7365_
NUE7366_
NUF6750_
Board, RF (VHF)
Board, RF (UHF1)
Board, RF (UHF2)
Board, RF (7/800)
10 3275623B03 Thermal Pad, Outer
11 75009299002 Thermal Pad, Inner
12 6003710K08 Battery, Backup, Coincell
13 3271829H02 Seal, Connector, Battery
14 MHLN5979_ Board, Vocon
15
1
01009364001 Assembly, Main, Chassis (W/O Control Top)
16 3275033C01 O-Ring, Antenna, Main
17 43009291001 Insert, Universal Connector
18 3971892H01 Contact, Chassis Ground
19 7505316J16 Pad, Coin Cell Battery
20 3075864B02 Cable, RF Coax
21
2
1375044C02 Assy, Control Top
22 3275031C01 Seal, Control Cap
23
2
75009418001 Pad, Support
24 1371891H01 Bezel, Control Top, Subassembly
25 4575585B01 Lever, Secure
26 0400129054 Washer, Lock, Antenna
27 0275891B01 Nut, Spanner, Antenna
28 3675590B03 Knob, Frequency
29 3675581B01 Knob, Volume
30 3275377H01 Seal, Cap, Torque Adder
31 0275361H01 Nut, Spanner, Volume
32 0405659W01 Washer, Wave, Volume
33 HLN5977_
HLN5978_
Std Expansion Board Kit
Opt Expansion Board Kit
34 NHN7016_ Module, Speaker
35 32009351001 Seal, Speaker Module
36 35009312002 Mic Mesh
37 3275002C03 Mic Membrane
38 NHN7021_ Grille, Speaker
39 33009261001
33009261002
33009261003
33009261004
Label, Grille, Speaker for APX6000
Label, Grille, Speaker for APX6000R
Label, Grille, Speaker for APX5000
Label, Grille, Speaker for APX5000R
40 33009271001 Label, Bluetooth APX 5000/ APX 6000/ APX 6000Li
41 0375962B02 Screw(x2), M2.5X0.45, 24.45
42 0375962B01 Screw(x2), M2.5X0.45, 3 0.1
43 0375962B03 Screw(x2), M2.5X0.45, 9.2
44 0375962B04 Screw(x2), M2.5X0.45, 7
45 3009304001 Screw, RF and Vocon Board
46 1575250H01 Cover, Connector, Universal Conncector
47 33009273001 Label, FM Outer
48 33009273002 Label, FM Inner
49 32009355001 Seal, Main
50
1
NHN7015_ Assembly, Main Chassis (with Control Top)
Item
No.
Motorola Part
Number
Description
