5.5 Transmitter Performance Checks
The following tables outline the performance checks for the transmitter.
Audio Output
Distortion
Mode: Proj 25 Std
RF Control: Gen
Output Level: -47 dBm
Proj 25 Dev: 2.83 kHz
Code: 1011 Hz PAT
Meter: Ext. Distortion
Radio Tuner
Software not used;
Radio: Out of
TEST MODE;
Select a
conventional
ASTRO channel
PTT to OFF
(center)
Meter selector to
Audio PA
Spkr/Load to
Speaker
Distortion < 3.0%
Residual
Audio Noise
Ratio
Mode: Proj 25 Std
RF Control: Gen
Output Level: -47 dBm
Proj 25 Dev: 2.83 kHz
Code:
A) 1011 Hz PAT
B) Silence PAT
Meter: AC Volts
As above As above Residual Audio Noise Ratio
-45 dB
* These tests require a communications system analyzer with the ASTRO 25 test options.
Table 5-9. Transmitter Performance Checks – APX 5000/ APX 6000/ APX 6000Li
Test Name System Analyzer Radio Test Set Comments
Reference
Frequency
RF Control: Monitor
Meter: RF Display
Display: Bar Graphs
Freq: Selected radio TX
freq.
TEST MODE CSQ
channel* or
programmed
conventional
channel
PTT to continuous
(during the
performance
check).
VHF: ±0.8 ppm
(±140 Hz)
UHF1: ±0.8 ppm
(±376 Hz)
UHF2: ±0.8 ppm
(±416 Hz)
700–800 MHz: ±0.8 ppm
(±696 Hz)
RF Power As above As above As above VHF: 1–6 Watts
UHF1: 1–5 Watt
UHF2: 1–5 Watt
700: 1–2.7 Watt
800: 1–3 Watt
Voice
Modulation
(external)
As above. Set fixed 1 kHz
audio level to 400 mV.
As above As above Deviation:
(12.5 kHz) ≥ 2.1 kHz, but
≤ 2.5 kHz
(25 kHz) ≥ 4.1 kHz, but
≤ 5.0 kHz
