Sec 2: 5-8 Performance Checks: Display Radio Test Mode (Top-Display Version)
5.2.5 CID Test Mode
To perform the CID Test:
1. Press and release Top Button (Orange button); all pixels are on.
2. Press any key; Checker box 1 test appears.
3. Press any key; Checker box 2 test appears.
4. Press any key; "4 bolder test" test appears on the top display.
5. Press any key; "Test completed" appears.
5.3 Display Radio Test Mode (Top-Display Version)
This section provides instructions for performing tests in non-display radio test mode.
5.3.1 Access the Test Mode
To enter the display radio test mode:
1. Turn the radio on.
2. Within 10 seconds after “SELF TEST” is complete, press Side Button 2 five times in
succession.
The radio shows a series of displays that give information regarding various version numbers
and subscriber specific information. The displays are described in Table 5-5.
Table 5-5. Test-Mode Displays
Name of Display Description Appears
Service The literal string indicates the radio has
entered test mode.
Always
Host version The version of host firmware is displayed. Always
DSP version The version of DSP firmware is displayed. Always
Secure version Version of the encryption software When the radio is secure
equipped
KGI algorithms name
(Encryption Type 1)
Type of encryption being used When the radio is secure
equipped
KG2 algorithms name
(Encryption Type 2)
Type of encryption being used When the radio is secure
equipped and 2 or more
algorithms are loaded
KG3 algorithms name
(Encryption Type 3)
Type of encryption being used When the radio is secure
equipped and 3 or more
algorithms are loaded
KG4 algorithms name
(Encryption Type 4)
Type of encryption being used When the radio is secure
equipped and 4 or more
algorithms are loaded
KG5 algorithms name
(Encryption Type 5)
Type of encryption being used When the radio is secure
equipped and 5 or more
algorithms are loaded
