Motorola APX 5000 User Manual

ASTRO APX 5000 VHF Model Chart Sec 1: ix
ASTRO APX 5000 VHF Model Chart
MODEL NUMBER
Top Display Model:
Dual Display (Limited Keypad):
Dual Display (Full Keypad):
Non-BT Models FCC ID:
BT Models FCC ID:
MODEL DESCRIPTION:
H98KGD9PW5_NI
H98KGF9PW6_NI
H98KGH9PW7_NI
AZ489FT3824
AZ489FT3929
VHF, APX 5000
Top Display Model
Dual Display Model (Limited Keypad)
Dual Display Model (Full Keypad)
ITEM NUMBER DESCRIPTION
XXX NHN7015_ Sub-Assembly, Main Chassis
X X NHN7020_ Display, Color
XXX NHN7021_ Grille, Speaker (Black)
XXX 0375962B01 Screw, Chassis (M2.5 x 30.1 mm)
XXX 0375962B02 Screw, Chassis (M2.5 x 24.45 mm)
XXX 0375962B03 Screw, Chassis (M2.5 x 9.2 mm)
XXX 0375962B04 Screw, Chassis (M2.5 x 7.0 mm)
XXX 1575250H01 Cover, Universal Connector
XXX 43009291001 Insert, Universal Connector
X 1575356H01 Cover, Belt Clip, Top Display
XXX 75009418001 Pad, Controls Flex Support
XXX 3271829H02 Seal, Battery Connector
XXX 3275623B03 Pad, Thermal, Outer
XXX 32009356002 Seal, Vacuum Port
XXX 33009261003 Label, Grille Top APX 5000
XXX 33009273001 Label, FM, External
XXX 33009273002 Label, FM, Internal
XXX 75009299002 Pad, Thermal, Inner
OOO HLN5978_ Opt Expansion Board Kit
XXX HLN5977_ Std Expansion Board Kit
XXX HLN5979_ Assembly, VOCON Board
X NHN7024_ Assembly, Main Housing, Dual Display/ Full Keypad (Black)
X NHN7027_ Assmbly, Main Housing, Dual Display/ Limited Keypad
X NHN7030_ Assembly, Main Housing, Top Display
XXX NHN7016_ Assembly, Speaker Module
X X NHN7013_ Sub-Assembly, Back Chassis, Dual Display
X NHN7014_ Sub-Assembly, Back Chassis, Top Display
XXX NUD7120_ Assembly, RF Board (VHF)
XXX NNTN7930_ User Guide CD, APX 5000
●●●NHN7022_ Grille, Speaker (Green)
●●●NHN7023_ Grille, Speaker (Yellow)
● NHN7025_ Assembly, Main Housing, Dual Display/ Full Keypad (Yellow)
● NHN7026_ Assembly, Main Housing, Dual Display/ Full Keypad (Green)
● NHN7028_ Assmbly, Main Housing, Dual Display/ Limited Keypad (Yellow)
● NHN7029_ Assmbly, Main Housing, Dual Display/ Limited Keypad (Green)
● NHN7031_ Assembly, Main Housing, Top Display (Yellow)
● NHN7032_ Assembly, Main Housing, Top Display (Green)
Note:
X = Item Included.
O = Option available.
● = Option available. Can be serviced in depot and ordered thru AAD.
• Refer
Appendix A for antennas, batteries and other applicable accessories.

Motorola APX 5000 Specifications

General

Brand	Motorola
Model	APX 5000
Category	Two-Way Radio
Language	English
