Exploded Views and Parts Lists: APX 6000XE Dual Display (Full Keypad) Exploded View Parts List Sec 2: 10-3
10.2 APX 6000XE Dual Display (Full Keypad)
Exploded View Parts List
NOTE:
1. Kit NHN7033_ includes Items #15–#20, #22, #26, #27, #44, #55–#58. When purchasing this kit, need to
purchase item #23 (qty. 2) together.
2. When purchasing item #58, need to purchase items #23 (qty. 2), #26, #27, #55–#57 together.
3. Item #58 comes with items #22 and #56.
4. Item #60 comes with items #40 and #59.
5. Items #40 and #59 are not orderable. Both items come with item #60.
Item
No.
Motorola Part
Number
Description
1 NHN7024_
NHN7025_
NHN7026_
NHN7069_
NHN7081_
Assy, Front Housing, Dual Display, M3, Black (Full Keypad)
Assy, Front Housing, Dual Display, M3, Yellow (Full Keypad)
Assy, Front Housing, Dual Display, M3, Green(Full Keypad)
Assy, Front Housing, Dual Display, M3, Black, Cyrillic (Full Keypad)
Assy, Front Housing, Dual Display, M3, Black, Arabic (Full Keypad)
2 33009265001 Medallion
3 NHN7013_ Assembly, Back Chassis, Dual Display
4 32009357001 Boot, Dataside Mic
5 3275002C03 Mic Membrane
6 35009312002 Mic Mesh
7 61009283002 Lens, Front Display
8 NHN7020_ Display, Front
9 MNUD7120_ Board, RF
10 3275623B03 Thermal Pad, Outer
11 75009299002 Thermal Pad, Inner
12 6003710K08 Battery, Backup, Coincell
13 3271829H02 Seal, Connector, Battery
14 NUD7120_
NUE7365_
NUE7366_
NUF6750_
Board, RF (VHF)
Board, RF (UHF1)
Board, RF (UHF2)
Board, RF (7/800)
15
1
01009364001 Assembly, Main, Chassis (W/O Control Top)
16 3275033C01 O-Ring, Antenna, Main
17 43009291001 Insert, Universal Connector
18 3971892H01 Contact, Chassis Ground
19 7505316J16 Pad, Coin Cell Battery
20 3075864B02 Cable, RF Coax
22 3275031C01 Seal, Control Cap
23
2
75009418001 Pad, Support
26 0400129054 Washer, Lock, Antenna
27 0275891B01 Nut, Spanner, Antenna
33 HLN5977_
HLN5978_
Std Expansion Board Kit
Opt Expansion Board Kit
34 NHN7016_ Module, Speaker
35 32009351001 Seal, Speaker Module
40
5
– Label, Bluetooth APX 6000
41 0375962B02 Screw(x2), M2.5X0.45, 24.45
42 0375962B01 Screw(x2), M2.5X0.45, 3 0.1
43 0375962B03 Screw(x2), M2.5X0.45, 9.2
44 0375962B04 Screw(x2), M2.5X0.45, 7
45 3009304001 Screw, RF and Vocon Board
46 1575250H01 Cover, Connector, Universal Conncector
47 33009273001 Label, FM Outer
48 33009273002 Label, FM Inner
49 32009355001 Seal, Main
54
1
NHN7033_ Assembly, Main Chassis (with Control Top)
55 36009257001 Knob, Volume
56 36009258001 Knob, Frequency
57 03009357001 Screw, Top Bezel
58
2,3
0180706J95
0180706K02
0180706K03
Control Cap Assembly, MT-XE – Black
Control Cap Assembly, MT-XE – Yellow
Control Cap Assembly, MT-XE – Green
59
5
– Sound Dampener
60
4
NHN7034_
NHN7036_
NHN7037_
Assembly, Speaker Grill – Black
Assembly, Speaker Grill – Yellow
Assembly, Speaker Grill – Green
61 07009369001 Support, Expander PCB
Item
No.
Motorola Part
Number
Description
