Specifications for APX 6000Li UHF1 Radios Sec 1: xxvii
Specifications for APX 6000Li UHF1 Radios
All specifications are per Telecommunications Industries Association TIA-603 unless otherwise
noted.
GENERAL RECEIVER TRANSMITTER
Temperature Range:
Operating: -30°C to +60°C
Storage: -40°C to +85°C
Power Supply:
Nickel-Metal-Hydride Battery (NiMH)
or Lithium-Ion Battery (Li-Ion)
Battery Voltage:
Nominal: 7.5 Vdc
Range: 6 to 9 Vdc
Transmit Current Drain (Typical): 1960 mA
Receive Current Drain (Rated Audio): 303 mA
Standby Current Drain: 133 mA
Recommended Battery:
Li-Ion (Slim): PMN4403_
or Li-Ion: NNTN7038_
or Li-Ion Ultra High Cap: NNTN7034_
or Li-Ion Ultra High Cap and FM: NNTN7033_
*
or NiMH: NNTN7037_
oor NiMH FM (Factory Mutual): NNTN7036_
*
* FM Intrinsically Safe.
Dimensions (H x W x D):
Without Battery (Radio Only):
H = 5.50" (139.7 mm)
W
1
= 2.98" (75.7 mm) / 2.37" (60.2 mm)
D
2
= 1.60" (40.5 mm) / 1.37" (34.7 mm)
With Slim Li-Ion Battery:
H = 5.76" (146.3 mm)
W
1
= 2.98" (75.7 mm) / 2.37" (60.2 mm)
D
2
= 1.65" (41.8 mm) / 1.37" (34.7 mm)
With NiMH Battery:
H = 7.76" (197.1 mm)
W
1
= 2.98" (75.7 mm) / 2.37" (60.2 mm)
D
2
= 1.65" (41.8 mm) / 1.37" (34.7 mm)
Note:
H = Height; W = Width; D = Depth
1 = (Width @ Top) / (Width @ PTT)
2 = (Depth @ Bottom) / (Depth @ PTT)
Weight: (w/o Antenna):
Less Battery: 10.7 oz (303 g)
With Li-Ion Slim: 15.7 oz (445 g)
With Li-Ion Ultra High Cap: 21.1 oz (559 g)
With NiMH: 22.3 oz (631 g)
Frequency Range: 380–470 MHz
Bandwidth: 90 MHz
Analog Sensitivity (typical)
(12 dB SINAD): 0.224 µV
Digital Sensitivity (typical)
(1% BER): 0.298 µV
(5% BER): 0.2 µV
Intermodulation (typical): -81.5 dB
Selectivity
(typical):
(25 kHz Channel): -77 dB
(12.5 kHz Channel): -66.7 dB
Spurious Rejection (typical): -80.5 dB
Frequency Stability
(-30+60°C; 25°C reference): ±0.000086%
Rated Audio:
Internal Speaker: 500 mW
External Speaker: 500 mW
FM Hum and Noise (typical):
25 kHz -53.5 dB
12.5 kHz -47.4 dB
Distortion (typical): 0.91 %
Channel Spacing: 12.5/25 kHz
Frequency Range: 380–470 MHz
RF Power:
380–470 MHz: 5 W
Frequency Stability (typical)
(-30 to +60°C; 25°C ref.): ±0.000035%
Emission (typical conducted): -75 dBc
FM Hum and Noise (typical)
(Companion Receiver): 25 kHz -49.5 dB
12.5 kHz -52 dB
Distortion (typical): 1%
Modulation Limiting: 25 kHz chnls ±5.0 kHz
20 kHz chnls ±4 kHz
12.5 kHz chnls ±2.5 kHz
ACPR (typical): 25 kHz -72 dBc
12.5 kHz -68 dBc
Emissions Designators:
11K0F3E, 16K0F3E, 8K10F1D, 8K10F1E,
8K10F1W, 20K0F1E
Specifications subject to change without notice.
