Motorola APX 5000 User Manual

Sec 2: 16 ASTRO APX 6000XE UHF1 Model Chart
ASTRO APX 6000XE UHF1 Model Chart
MODEL NUMBER
Top Display Model:
Dual Display (Limited Keypad):
Dual Display (Full Keypad):
Non-BT Models FCC ID:
BT Models FCC ID:
MODEL DESCRIPTION:
H98QDD9PW5_N
H98QDF9PW6_N
H98QDH9PW7_N
AZ489FT4899
AZ489FT4892
UHF1, APX 6000XE
Top Display Model
Dual Display Model (Limited Keypad)
Dual Display Model (Full Keypad)
ITEM NUMBER DESCRIPTION
XXX NHN7033_ Sub-Assembly, Main Chassis
●●● NHN7042_ Sub-Assembly, Main Chassis (Yellow)
●●● NHN7043_ Sub-Assembly, Main Chassis (Green)
X X NHN7020_ Display, Color
XXX NHN7034_ Grille, Speaker (Black)
●●● NHN7036_ Grille, Speaker (Yellow)
●●● NHN7037_ Grille, Speaker (Green)
XXX 0375962B01 Screw, Chassis (M2.5 x 30.1 mm)
XXX 0375962B02 Screw, Chassis (M2.5 x 24.45 mm)
XXX 0375962B03 Screw, Chassis (M2.5 x 9.2 mm)
XXX 0375962B04 Screw, Chassis (M2.5 x 7.0 mm)
XXX 1575250H01 Cover, Universal Connector
XXX 43009291001 Insert, Universal Connector
X 1575356H01 Cover, Belt Clip, Top Display
XXX 75009418001 Pad, Controls Flex Support
XXX 3271829H02 Seal, Battery Connector
XXX 3275623B03 Pad, Thermal, Outer
XXX 32009356002 Seal, Vacuum Port
XXX 33009261001 Label, Grille Top APX 6000
XXX 33009273001 Label, FM, External
XXX 33009273002 Label, FM, Internal
XXX 75009299002 Pad, Thermal, Inner
XXX 07009369001 Support, Expander PCB
OOO HLN5978_ Opt Expansion Board Kit
XXX HLN5977_ Std Expansion Board Kit
XXX HLN5979_ Assembly, VOCON Board
X NHN7024_ Assembly, Main Housing, Dual Display/ Full Keypad (Black)
● NHN7025_ Assembly, Main Housing, Dual Display/ Full Keypad (Yellow)
● NHN7026_ Assembly, Main Housing, Dual Display/ Full Keypad (Green)
X NHN7027_ Assmbly, Main Housing, Dual Display/ Limited Keypad
● NHN7028_ Assmbly, Main Housing, Dual Display/ Limited Keypad (Yellow)
● NHN7029_ Assmbly, Main Housing, Dual Display/ Limited Keypad (Green)
X NHN7030_ Assembly, Main Housing, Top Display
● NHN7031_ Assembly, Main Housing, Top Display (Yellow)
● NHN7032_ Assembly, Main Housing, Top Display (Green)
XXX NHN7016_ Assembly, Speaker Module
X X NHN7013_ Sub-Assembly, Back Chassis, Dual Display
X NHN7014_ Sub-Assembly, Back Chassis, Top Display
XXX MNUE7365 Assembly, RF Board (UHF1)
XXX PMLN5817 User Guide CD, APX 6000XE
● NHN7069_ Assembly, Main Housing, Dual Display/Full Keypad, Cyrillic (Black)
● NHN7081_ Assembly, Main Housing, Dual Display/Full Keypad, Arabic (Black)
Note:
X = Item Included.
O = Option available.
● = Option available. Can be serviced in depot and ordered thru AAD.
• Refer
Appendix A for antennas, batteries and other applicable accessories.
