Sec 1: 5-4 Performance Checks: Display Radio Test Mode (Dual-Display Version)
NOTE: All displays are temporary and will expire without any user intervention. If
information is longer than the physical length of the radio’s display, the information
will wrap around to the next display. After the last display, “RF TEST” is displayed.
To freeze any of the displays, press the left arrow on the 4-Way Navigation Button.
To resume automatic scrolling, press the right arrow on the 4-Way Navigation
Button. To rapidly scroll forward through the displays, continue pressing the right
arrow. You cannot scroll backwards.
NOTE: Press the Top Side Button (Purple button) to advance the test environments from
“RF TEST”, “CH TEST”, “RGB TEST”, “CID TEST” then press the
Top Button (Orange button) to confirm selection. Press any other buttons to
advance the test.
Once a test is carried out, restart the radio to proceed to another test.
3. Do one of the following:
•Press the Top Side Button to stop the displays and toggle between RF test mode and the
Control Top and Keypad test mode. The test mode menu “CH TEST” is displayed,
indicating that you have selected the Control Top and Keypad test mode. Go to Section
“5.2.3 Control Top and Keypad Test Mode” on page 1:5-6.
ROM Size The memory capacity of the host FLASH
part
Always
FLASHcode The FLASH codes as programmed in the
codeplug
Always
RF band 1 The radio’s operating frequency Always
Tuning Ver Version of Tuning codeplug Always
Proc Ver Version of Processor Always
Option Board
Type
Type of Option board being used When the radio has an Option
Board/ Mace with Apps
Expansion Board
Option Board
Serial Number
Serial number of the Option board is
displayed
When the radio has an Option
Board/ Mace with Apps
Expansion Board
Option Board
Bluetooth Addr
Bluetooth Address of the Option board is
displayed
When the radio has an Option
Board/ Mace with Apps
Expansion Board
Option Board
SW Version
Software version of the Option Board is
displayed
When the radio has an Option
Board/ Mace with Apps
Expansion Board
Exp Board Type Type of Expansion Board is displayed When the radio has an
Expansion Board
Table 5-2. Test-Mode Displays (Continued)
Name of Display Description Appears
To Next Page
