Motorola EP350 Basic Service Manual

3-2 Test Equipment, Service Aids, and Service Tools: Service Aids
3.2 Service Aids
Table 3-3. lists service aids recommended for working on the EP350 Series Radios. While all of these
items are available from Motorola, most are standard shop equipment items, and any equivalent item
capable of the same performance may be substituted for the item listed.
Note: 1.Use PMDN4040BR or higher for tuning the EP350 Series radios as PMDN4040AR cannot be used to
perform this function.
Table 3-3. Service Aids
Motorola Part
No.
Description Application
PMDN4038_R Knob Remover/Chassis Opener Used to remove the front cover assembly.
PMDN4039_R Crab Eye Nut Opener Used to remove the crab eye nut.
PMDN4040_R
1
Radio Test Box Enables communication between the radio, test
equipment and the computer's USB port.
PMDN4041_R RF Adaptor Adapts radio’s antenna port to BNC cabling of test
equipment.
PMDN4076_R Radio to Radio Cloning Cable Allows a radio to be duplicated from a master radio by
transferring programmed data from the master radio to
the other.
PMDN4077_R Programming Cable Used to program the radio through Customer
Programming Software and Radio Tuner.
PMDN4079_R GND Plate Interconnects radio’s chassis to RF Adaptor.
PMDN4080_R Battery Eliminator Interconnects radio to power supply.

Motorola EP350 Specifications

General

Channel Capacity	16 channels
IP Rating	IP54
Drop Resistance	1.2 meters
Frequency Range	VHF: 136-174 MHz, UHF: 403-470 MHz
Battery Life	Up to 11 hours
Power Supply	7.5 V (Nominal)
Waterproof	Splashproof
Dimensions	127.6 x 62 x 42 mm (with standard battery)
