Motorola EP350 Basic Service Manual

Maintenance – EP350 (Limited Keypad Model): Disassembling and Reassembling the Radio 7-7
7.5.1 Radio Disassembly – Detailed
7.5.1.1 Front Housing From Chassis Disassembly
1. Turn off the radio.
2. Remove the Battery (29):
a. Release the battery latch by moving it into the unlock position.
b. Slide the Battery downwards.
c. Remove the Battery from the radio
3. Remove the Antenna (21) by turning it counterclockwise.
Figure 7-38. Battery and Antenna Removal
Antenna
Belt Clip
Battery
Battery Latch

Motorola EP350 Specifications

General

Channel Capacity	16 channels
IP Rating	IP54
Drop Resistance	1.2 meters
Frequency Range	VHF: 136-174 MHz, UHF: 403-470 MHz
Battery Life	Up to 11 hours
Power Supply	7.5 V (Nominal)
Waterproof	Splashproof
Dimensions	127.6 x 62 x 42 mm (with standard battery)
