Motorola EP350 Basic Service Manual

Maintenance – EP350 (Full Keypad Model): Mechanical View and Parts List 6-19
Table 6-13. Parts List (Full Keypad without Channel Knob)
Item Motorola Kit Number Description Quantity
1 PMDN4087_R Front Housing, Full Keypad 1
2 PMDN4086_R Name Plate (EP350) 1
3 PMDN4124_R Double Molded Cover, PTT 1
4 PMDN4090_R Seal, Volume Knob 1
5 PMDN4088_R Adhesive, Top Control 1
6 PMDN4104_R Escutcheon, Top without Channel knob 1
7 PMDN4102_R Knob, Volume 1
8 PMDN4100_R Felt, Speaker 1
9 PMDN4067_R Speaker 1
10 PMDN4099_R Retainer, Speaker, with screw 1
11 PMDN4098_R Insulator, Speaker 1
12 PMDN4135_R Seal, Microphone 1
13 PMDN4139_R Microphone 1
14 PMDN4111_R Flexible Cable, Sub Circuit Board 1
15 PMDN4129_R Sub Circuit Board, w/o Channel 1
16 PMDN4112_R
Crab-Eye Nut, Volume and Channel
1
17 PMDN4134_R Switch, Tact 3
18
*
PMDE4010_R
PMDD4011_R
PMDE4028_R
Main Circuit Board (EP350 – PMUE3148_AL)
Main Circuit Board (EP350 – PMUD2437_AL)
Main Circuit Board (EP350 – PMUE3320_AL)
1
19 PMDN4114_R Screw, RF Support 1
20 PMDN4138_R Bracket, Antenna 1
21 See Appendix A Antenna 1
22 PMDN4116_R
O
-ring
1
23
^
PMDN4120_R Finger Strip, Chassis 2 (UHF2 and VHF)
3 (UHF1)
24 PMDN4121_R Pad, Thermal 1
25 PMDN4122_R Chassis 1
26 PMDN4105_R Seal, Battery Contact 1
27 PMDN4110_R Label, Caution 1
28 See Appendix A Belt Clip 1
29 See Appendix A Battery 1
30 PMDN4028_R Tuning Hole Sticker (Small) 1
31 PMDN4106_R Gel Pad, Ceramic Filter 1
32 0915184H01 Contact, Battery 1
33 PMDN4108_R Bracket, Accessory 1
34 0980683Z01 Jack, Audio 1

Motorola EP350 Specifications

General

Channel Capacity	16 channels
IP Rating	IP54
Drop Resistance	1.2 meters
Frequency Range	VHF: 136-174 MHz, UHF: 403-470 MHz
Battery Life	Up to 11 hours
Power Supply	7.5 V (Nominal)
Waterproof	Splashproof
Dimensions	127.6 x 62 x 42 mm (with standard battery)
