Motorola EP350 Basic Service Manual

6-20 Maintenance – EP350 (Full Keypad Model): Mechanical View and Parts List
Note:
*
This kit consists of tact switch, antenna bracket, PCB finger strip, battery contact and audio jack.
‡
This kit consists of microphone and microphone seal.
^
This kit is applicable for VHF, UHF1 and UHF2.
#
This kit is only applicable for UHF1.
35 PMDN4107_R Screw, Machine 7
36 PMDN4123_R Module, Liquid Crystal Display 1
37 PMDN4109_R Flexible Cable, Main Circuit Board 1
38 PMDN4119_R Screw, Tapping 5
39
‡
PMDN4130_R Front Circuit Board, FKP 1
40 PMDN4113_R Cover, Dust 1
41 PMDN4115_R Keypad, Full Keypad 1
42
#
PMDN4148_R Finger Strip RX 2
43
#
PMDN4150_R Finger Strip, T PCB 1
Table 6-13. Parts List (Full Keypad without Channel Knob) (Continued)
Item Motorola Kit Number Description Quantity

Motorola EP350 Specifications

General

Channel Capacity	16 channels
IP Rating	IP54
Drop Resistance	1.2 meters
Frequency Range	VHF: 136-174 MHz, UHF: 403-470 MHz
Battery Life	Up to 11 hours
Power Supply	7.5 V (Nominal)
Waterproof	Splashproof
Dimensions	127.6 x 62 x 42 mm (with standard battery)
