Motorola EP350 Basic Service Manual

Chapter 5 Radio Programming and Tuning
5.1 Introduction
This chapter provides an overview of the EP350 Series Customer Programming Software (CPS) and
the CP/EP/P Tuner as designed for use in a Windows
®
2000/XP/Vista environment. Both cover all the
functions of the traditional Radio Service Software (RSS) package.
They are both available in the CPS CDROM (PMVN4161_) and Entry Level Radio Tuner
CDROM (PMVN4165_).
5.2 CPS Programming Setup
Refer to online help files for the CPS Programming procedures.
(See Figure 5-5. CPS Programming Setup for CPS Programming Setup).
5.3 Radio-to-Radio Cloning
1. Cloning is the process of copying the content of one radio (source radio) into another radio
(destination radio). Radio content refers to system-type features such as frequency, squelch type
option, etc.
2. The cloning can be done only if all the following conditions are met:
a. The source radio's serial number cannot be blank.
b. The source radio and the destination radio must have the same model number.
c. The source radio and the destination radio must have an identical major codeplug
version.
3. Radio functionality inherent in one radio cannot be cloned to another radio that does not contain
the same functionality. Tuning and alignment information are not transferable and are not
affected by cloning.
Figure 5-5. CPS Programming Setup
USB
Same Cable
Program Cable PMDN4077_R
2.5mm stereo
USB connection

Motorola EP350 Specifications

General

Channel Capacity	16 channels
IP Rating	IP54
Drop Resistance	1.2 meters
Frequency Range	VHF: 136-174 MHz, UHF: 403-470 MHz
Battery Life	Up to 11 hours
Power Supply	7.5 V (Nominal)
Waterproof	Splashproof
Dimensions	127.6 x 62 x 42 mm (with standard battery)
