7 - 16 MC70 Integrator Guide
Key Entry Page
If you select either 40-Bit WEP or 128-Bit WEP the wizard proceeds to the key entry dialog box unless the Use
Passkey
check box was selected in the Encryption dialog box (see Figure 7-21 on page 7-14). The Key Entry
dialog box will be shown only if the authentication is set to
None.To enter the key information:
1. Enter the 40-bit or 128-bit keys into the fields.
2. Tap Next.
Figure 7-22
40-Bit and 128-Bit WEP Keys Dialog Boxes
Passkey Dialog
When you select None as an authentication and WEP as an encryption, you can choose to enter a passkey by
checking the
Use PassKey check box. The user is prompted to enter the passkey. For WEP, the Use PassKey
checkbox is only available if the authentication is None.
When you select None as an authentication and
TKIP as an encryption, you must enter a passkey. The user
cannot enter a passkey if the encryption is
TKIP and the authentication is anything other than None.
When you select
None as an authentication and AES as an encryption, you must enter a passkey. The user
cannot enter a passkey if the encryption is
AES and the authentication is anything other than None.
Figure 7-23
Passkey Dialog Box
Tap
Next. The IP Mode dialog box displays.
IP Mode
Use the IP Mode dialog box to configure network address parameters: IP address, subnet, gateway, DNS, and
WINS.
40-Bit WEP Keys Dialog Box
128-Bit WEP Keys Dialog Box
