Wireless Applications 7 - 19
Figure 7-28
Transmit Power Dialog Box (Ad-Hoc Mode)
Tap
Next to display the Battery Usage dialog box.
Battery Usage
Use the Battery Usage dialog box to select power consumption of the wireless LAN. There are three settings
available: CAM, Fast Power Save, and MAX Power Save. Battery usage cannot be configured in Ad-Hoc
profiles.
Table 7-15
Transmit Power Dialog Box (Infrastructure Mode)
Field Description
Automatic Select Automatic (the default) to use the AP power level.
Power Plus Select
Power Plus to set the EDA transmission power one level higher than the level
set for the AP.
Table 7-16
Power Transmit Options (Ad-Hoc Mode)
Field Description
Full Select Full power for the highest transmission power level. Select Full power when
operating in highly reflective environments and areas where other devices could be
operating nearby, or when attempting to communicate with devices at the outer edge of a
coverage area.
30 mW Select
30 mW to set the transmit power level to 30 mW.
15 mW Select
15 mW to set the transmit power level to 15 mW.
5 mW Select
5 mW to set the transmit power level to 5 mW.
1 mW Select
1 mW for the lowest transmission power level. Use this level when communicating
with other devices in very close proximity, or in instances where you expect little or no radio
interference from other devices.
