7 - 20 MC70 Integrator Guide
Figure 7-29
Battery Usage Dialog Box
Manage Profiles Application
The Manage Profiles window provides a list of user-configured wireless profiles. Define up to 32 profiles at any
one time. To open the
Manage Profiles window, tap the Signal Strength icon > Manage Profiles.
Figure 7-30
Manage Profiles Window
NOTE Power consumption is also related to the transmit power settings.
Table 7-17
Battery Usage Options
Field Description
CAM Continuous Aware Mode (CAM) provides the best network performance, but
yields the shortest battery life.
Fast Power Save
Fast Power Save (the default) performs in the middle of CAM and MAX Power
Save with respect to network performance and battery life.
MAX Power Save
Max Power Save yields the longest battery life while potentially reducing
network performance. In networks with minimal latency, Max Power Save
performs as well as Fast Power Save, but with increased battery
conservation.
