Accessories 2 - 3
Figure 2-2
Card Cover Removal
3. Insert the card with the card contacts facing down and the cut corner on the right, until you feel a click.
4. Replace the housing cover and secure with the screws.
To remove an MMC/SD card:
1. Power off the EDA.
2. Remove the card cover at the top of the EDA by loosening the screws and lifting the cover out of the slot.
3. Using the stylus, press and release the card to eject it.
4. Remove the card from the card slot.
5. Replace the card cover.
SD/SDIO Setup
Use the SDSwitch Settings application to indicate the type of card installed in the SD slot.
1. Tap Start > Settings > System tab > SDSwitch icon.
Figure 2-3
SDSwitch Settings Window
2. In the SD Driver Mode section, select the type of SD card installed in the SD slot.
Tap the
SDIO Mode radio button if an SDIO card is installed in the SD slot.
NOTE On devices with AKU 3.2 and higher, the SDSwitch Settings application is installed.
