4 - 14 MC70 Integrator Guide
Scanning RD Bar Codes
When the EDA scans and successfully decodes a single or multiple RD bar codes, the data encoded in the bar
code can:
•
Reset the EDA’s connection profile. A connection profile is a set of Wireless Application parameters that
the EDA uses to access the wireless network.
•
Initiate downloads of one or more software packages from an FTP server to the EDA.
To scan an RD bar code:
1. Obtain the appropriate RD bar code(s) from the MSP Administrator.
2. Launch the RD application on the EDA. The Rapid Deployment window displays.
Table 4-4
Rapid Deployment Window
Text Box/Button Description
Please scan all of the bar
codes...
Displays the status of a scanned bar code.
Waiting - indicates the
EDA
is ready to scan a bar code.
OK - indicates the
EDA
successfully scanned a bar code. (The Indicator LED bar
on the
EDA
turns green and a beep sounds).
If there are no bar codes left to scan, the Rapid Deployment Configuring window
displays.
Bar codes left to scan... Displays a list of any remaining bar codes to scan (1-D bar codes only). When all
required bar codes are scanned successfully, the Rapid Deployment Configuring
window displays.
About Displays the Rapid Deployment Client Info window.
Reset Removes any previously scanned data.
Exit Closes the application. A confirmation window displays. Tap
Yes
to exit or
No
to
return to the Rapid Deployment window.
Note: Exiting the application prior to scanning all required bar codes discards any
scanned data collected up to that point.
NOTE Currently, RD only recognizes AirBEAM software packages. See AirBEAM Smart on page 4-16 for more
information.
