Wireless Applications 7 - 39
Tapping OK sends the credentials though WCS API. If there are no credentials entered, a dialog box displays
informing the user which field was not entered.
The
Log Off button only displays when a user is already logged on. When the Log Off button is tapped, the user
is prompted with three options: Log Off, Switch Users, and Cancel. Switching users logs off the current user
and re-initialize the login dialog box to be displayed for when there is no user logged on. Logging off logs off
the current user and close the login dialog box. Tapping
Cancel closes the Log Off dialog box and the Login
dialog box displays.
When the user is logged off, the EDA only roams to profiles that do not require credentials or to profiles that
were created with the credentials entered into the profile
The
Cancel button closes the dialog without logging into the network. If the login dialog was launched by the
WCS and not by the user, tapping
Cancel first causes a message box to display a warning that the cancel
disables the current profile. If the user still chooses to cancel the login at this point, the profile is cancelled.
Once a profile is cancelled, the profile is suppressed until a user actively re-enables it or a new user logs onto
the EDA.
