TN-5516/5518 User’s Manual Featured Functions
3-73
Database Option
Setting Description Factory Default
Local
(Max. 32 users)
Select this option when setting the Local User Database
as the authentication database.
Local
Radius Select this option to set an external RADIUS server as
the authentication database. The authentication
mechanism is EAP-MD5.
Local
Radius, Local Select this option to make using an external RADIUS
server as the authentication database the first priority.
The authentication mechanism is EAP-MD5 The first
priority is to set the Local User Database as the
authentication database.
Local
Radius Server
Setting Description Factory Default
IP address or
domain name
The IP address or domain name of the RADIUS server local host
Server Port
Setting Description Factory Default
Numerical The UDP port of the RADIUS server 1812
Shared Key
Setting Description Factory Default
alphanumeric
(Max. 40
characters)
A key to be shared between the external RADIUS server
and TN-5500. Both ends must be configured to use the
same key.
None
Re-Auth
Setting Description Factory Default
Enable/Disable Select to require re-authentication of the client after a
preset time period of no activity has elapsed.
Disable
Re-Auth Period
Setting Description Factory Default
Numerical
(60 to 65535 sec.)
Specify how frequently the end stations need to reenter
usernames and passwords in order to stay connected.
3600
802.1X
Setting Description Factory Default
Enable/Disable Click the checkbox under the 802.1X column to enable
IEEE 802.1X for one or more ports. All end stations
must enter usernames and passwords before access to
these ports is allowed.
Disable
