3.4. Extraction probes
The analyzer is available with either a probe with fixed probe tube or with ex-
changeable probe tubes. A complete list of available probe options can be
found in our effective price list.
Here 2 variants are shown as examples:
1
Probe tube
2
Probe cone (high grade steel)
3
Triple hose (NBR or Viton)
4
Connector for sample gas measurement
5
Connector for draft measurement
6
Connector for temperature measurement
Probe ST
With 180 mm probe pipe
(fixed)
and 1,5 m sampling line
Probe SF
With 300 mm exchangeable
probe pipe and 2,7 m sam-
pling line
