Operation of the System
SUPREMATouch
27
US
The following input data is shown in this display:
No. The number of the measured input in the system. This number is set by the sys-
tem and cannot be changed by the user.
Tag The customer defined input description is displayed here.
Value Numerical value and dimension of measurement. The measured values are dis-
played in intervals of 1 second, as long as they are within the measuring range. If
the measuring range is exceeded, the highest value reached is retained. In the
case of signal failure or an alarm suppression [during the warm-up period of spe-
cific sensor types], dashes are displayed instead of the measured value.
Status Current status of the input. The status is updated at intervals of 1 second and the
following values can be displayed:
- “Measure”
- “Calib.” [ measurement point in calibration mode]
- “Inhibit” [measurement point inhibited]
- “Overflow” [Measured value above full scale]
- “SignalErr.” [Measured value below measurement range, or value missing]
- “SystemErr.” [It was not possible for the MDO to get the measured value]
- “PA-failed” [presetting error]
- For specific sensor types, text can be defined for special statuses. These are
labelled with "F:“ [e.g. "F:OpticErr"]. The property is then equivalent to "Signal
error".
- “suppressed” [alarm suppressed during warm-up period of specific sensor
types]
- alarms 1, 2, 3 and 4
- Free [sensor has not been installed]
