SUPREMATouch
42
Operation of the System
MSA
US
To remove password protection completely, delete the password. Authorisation can then be ob-
tained only with the key switch or a higher-level password. If all passwords are deleted, a key
switch must be present to obtain the authorisation
To guard against typing errors the new password must be entered identically in the Password and
Confirmation field before it becomes valid.
Signal if Inhibited
Field type: Selection
If a MAO module is used to output sensor signals, there are three different ways of analogue sig-
nal behaviour for inhibited inputs:
- pass: The received measurement values are sent on.
- hold: The last measured value before inhibiting occurred is retained.
- maintain: The signal goes to the maintenance level [corresponds to 3.0 mA].
Operating Mode:
Field type: Display
This field shows the current operating mode of the SUPREMATouch system. Only two operating
modes are available ‘Standard’ for all countries except China and ‘GB16808-2008’ which is only
for use in China. All information, including the approval information in this manual refer to the
“Standard” operating mode.
OK
Field type: Button
Tap this button to accept the settings entered. After the button is tapped, the parameters are im-
mediately checked to see if they are valid. If the parameters are valid, they become part of the
system’s parameter set. If they are not valid, a warning appears.
Cancel
Field type: Button
Tap this button to discard the settings entered.
The setting in this field is essential for all measuring points in the whole system.
