HYDROCAL 1005 Manual for Installation and Operation Page 47/111
Selection of different input possibilities for the input mode [Mode], and the unit [Unit] -
See below.
Store alarm configuration and exit
Exit without storage
The following inputs signal can be selected by pressing the button:
The first 6 can be set-up in 0..80VAC, 0..20mA AC, 0..20 mA or 4..20 mA
The last 4 can be set-up in 0..20 mA or 4..20 mA
The following unit s can be selected by pressing button:
… (No unit)
ppm
ppm/Day
ppm/Week
ºC
%
mA
A
KA
V
KV
The external sensors names in the field "External sensor #" are edited by arrow keys and confirmed
by
and the alphanumeric keyboard.
The sample interval in the field "Sample interval" is edited by arrow keys and confirmed by
and the alphanumeric keyboard. The sample interval is made in seconds or by a button in days
hours min - seconds. For minus the button and for a double point the button are used.
After confirmation by the
button, the value will be converted and displayed in days hours min
- seconds.
For conversion of input units, the inputs „Minimum Value“ are made under the input signals 0V, 0 mA
or 4 mA and „Maximum Value“ are made under the input signals 10V or 20mA. In addition, the dis-
play range can be limited by inputting introduction of „Minimum Display“ and „Maximum Display“.
Remark: on following display, you could see 4 additional inputs named:
#11: H.-Spot for Hot-Spot Temperature
#12: Ag.Rate for Ageing Rate
#13: L.o.life for loss of Life
#14:
All of them are virtual sensors and any cases have to be considered as real analog inputs. However
these values are displayed on the main display as external sensors (See Chapter 3.3: Main Menu
“External sensor setup”).
