MP7505 Series User Manual
25
next page, and press the Order softkey, the Order menu item is highlit. In Parameter
5 of Figure 5-10, a blinking cursor appears in the parameter value of order. Turn the
rotary control to change the value directly, or use the numeric keypad to input the
desired value, which can be set from 2 to 16.
Set the harmonic amplitude of each order
After entering the harmonic setting menu, press the NextPage softkey to enter the
next page.
(1) Select the sequence number of the harmonic: Press the SN softkey, the SN
menu item is highlit. In Parameter 6 of Figure 5-10, a blinking cursor appears in
the parameter value of SN. Turn the rotary control to change the value directly,
or use the numeric keypad to input the desired value.
(2) Set the amplitude of the selected SN: Press the Amplitude softkey, the
Amplitude menu item is highlit. In Parameter 7 of Figure 5-10, a blinking cursor
appears in the parameter value of Amplitude. Turn the rotary control to change
the value directly, or use the numeric keypad to input the desired value and
choose the unit.
Set the harmonic phase of each order
After entering the harmonic setting menu, press the NextPage softkey to enter the
next page.
(1) Select the sequence number of the harmonic: Press the SN softkey, the SN
menu item is highlit. In Parameter 6 of Figure 5-10, a blinking cursor appears in
the parameter value of SN. Turn the rotary control to change the value directly,
or use the numeric keypad to input the desired value.
(2) Set the phase for the selected SN: Press the Phase softkey, the Phase menu item
is highlit. In Parameter 8 of Figure 5-10, a blinking cursor appears in the
parameter value of Phase. Turn the rotary control to change the value directly,
or use the numeric keypad to input the desired value and choose the unit.
Output the Modulated Waves
Supported modulation types include: AM (Amplitude Modulation), FM (Frequency
Modulation), PM (Phase Modulation), PWM (Pulse Width Modulation), ASK
(Amplitude Shift Keying), PSK (Phase Shift Keying), FSK (Frequency Shift Keying), 3FSK
(Ternary Frequency Shift Keying), 4FSK (Quadrature Frequency Shift Keying), BPSK
(Biphase Phase Shift Keying), QPSK (Quadrature Phase Shift Keying), OSK (Oscillating
Keying), SUM (Sum Modulation), DSB-AM (Double-Sideband Amplitude Modulation).
Press the Mod function key, then press the Type softkey, turn the rotary control to
select the modulation type, press the OK softkey to enter the setup menu. To turn off
the modulation, press the Mod function button again.
Note: The following output modulation waveform uses CH1 as an example. If you
need to set CH2, please refer to CH1 operation.
