MP7505 Series User Manual
select INTER and press the Arb file softkey. Turn the rotary control to select
one of the USER files (EditMemory cannot be selected) and press the Save
softkey. (The file size is displayed on the right side of the USER file. If 0B is
displayed, it means the file is empty.)
Description: EditMemory is a temporary data space created, saved, edited or
recalled by any arbitrary wave. Saving the waveform is to save the data of this
space to the user-specified location (EditMemory is in the memory and never
empty). The data in this space is changed after an arbitrary waveform is called, a
new waveform is created, or a related programming command is received.
If you want to save to a USB storage device, you need to plug the USB
storage device into the front panel USB interface. Turn the rotary control to
select USBDEVICE. Press the Arb file softkey and the instrument will list the
directories of the folders and files in the USB storage device. You can turn
the rotary control to select a folder or file. Press the Enter softkey to enter
the currently selected folder. To return to the parent directory, press the
Back softkey. After selecting the storage path, press the SaveAs softkey and
the input keyboard appears on the screen. Turn the rotary control to select
a character. Press the ABC/abc softkey to toggle the case of keyboard
characters. Press the Select softkey to enter the current character. Press the
Delete softkey to delete the last character that has been entered. Press the
Done softkey to finish editing and the waveform will be saved in the bin file
format under the current path.
Bring up arbitrary wave files in internal/external memory
Press the front panel Store function key to enter the file system.
To call up the waveform file in the internal memory, select INTER under the
memory selection interface and press the Arb file softkey. Turn the rotary
control to select a file and press the CallOut softkey. If the reading is successful,
the screen will prompt “File Read Successful”.
Description: The file size is displayed on the right side of the file. If 0B is
displayed, the file is empty.
To recall the waveform file in the USB storage device, turn the rotary control to
select USBDEVICE in the memory selection interface. Press the Arb file softkey
and the instrument will list the directories of the folders and files in the USB
storage device. Turn the rotary control to select a folder or file. Select the file
with the suffix of bin and press the CallOut softkey. If the reading is successful,
the screen will prompt “File Read Successful”.
