MP7505 Series User Manual
Harmonic amplitude Each harmonic amplitude can be set
Harmonic phase Each harmonic phase can be set
Modulation Characteristics
Modulation Characteristics
Modulation Type
AM, DSB-AM, FM, PM, ASK, FSK, PSK, BPSK, QPSK, 3FSK, 4FSK, OSK,
PWM, SUM
AM
Carrier Sine wave, square wave, ramp wave, arbitrary wave (except DC)
Modulated signal source Internal or external
Internal modulation
waveform
Sine wave, square wave, ramp wave, white noise, arbitrary waveform
Internal amplitude
modulation frequency
2 mHz to 1 MHz
Depth 0% to 120%
DSB-AM
Carrier Sine wave, square wave, ramp wave
Modulated signal source Internal or external
Internal modulation
waveform
Sine wave, square wave, ramp wave
Internal amplitude
modulation frequency
2 mHz to 1 MHz
Depth 0% to 100%
FM
Carrier Sine wave, square wave, ramp wave, arbitrary wave (except DC)
Modulated signal source Internal or external
Internal modulation
waveform
Sine, square, ramp, white noise, and arbitrary waveforms
Internal modulation
frequency
2 mHz to 1 MHz
Frequency offset 2 mHz ≤ offset ≤ min (carrier frequency, carrier maximum frequency -
carrier frequency) by default, the smaller of the two
PM
Carrier Sine wave, square wave, ramp wave, arbitrary wave (except DC)
Modulated signal source Internal or external
Internal modulation
waveform
Sine, square, ramp, white noise, and arbitrary waveforms
Internal phase
modulation frequency
2 mHz to 1 MHz
Phase deviation range 0° to 180°
PWM
Carrier Pulse wave
Modulated signal source Internal or external
