MP7505 Series User Manual
Utility Function Setting
Press the front panel Utility function key to enter the utility menu. You can set the
parameters of the generator such as: display settings, CH1/2 settings, I/O setup, and
system settings. Press Utility again to exit the utility menu.
Display Settings
Brightness Control
(1) Press the front panel Utility function key, press the Display softkey.
(2) Press the Backlight softkey to select Backlight.
(3) Turn the rotary control to adjust the value on the current cursor, use the
/ direction key to move cursor left or right, or use the numeric keypad to
enter the parameter and then select % as unit. The range is from 0% to 100%.
Screen Saver
If there is no operation within the set screen saver time, the screen enters the
protection mode (minimize screen brightness to protect the screen and save energy).
Press any key (except the power button) to restore the brightness before entering
the screen saver.
(1) Press the front panel Utility function key, press the Display softkey.
(2) Press the ScrSaver softkey to select On or Off.
(3) At On status, you can set the screen saver time. Turn the rotary control to adjust
the value on the current cursor, use the / direction key to move cursor
left or right, or use the numeric keypad to enter the parameter and then select
Minute as unit. The screen saver time range is 1 to 999 minutes.
Separator
The user can set the separator of the screen display data.
(1) Press the front panel Utility function key, press the Display softkey.
(2) Press the Separator softkey to toggle between Comma, Space, and Off.
Taking the frequency parameter as an example:
Comma
Space
Off
