MP7505 Series User Manual
56
 Repeat this step to set all the points.
 Press Write to enter the file system interface.
If you want to save the waveform to the internal memory, select INTER and
press Enter softkey. Turn the rotary control to select one of the USER files
(EditMemory cannot be selected) and press the Save softkey. (The file size is
displayed on the right side of the USER file. If 0B is displayed, it means the
file is empty.)
Description: EditMemory is a temporary data space created, saved, edited or
recalled by any arbitrary wave. Saving the waveform is to save the data of
this space to the user-specified location (EditMemory is in the memory and
never empty). The data in this space is changed after an arbitrary waveform
is called, a new waveform is created, or a related programming command is
received.
 If you want to save to a USB storage device, you need to plug the USB
storage device into the front panel USB port. Turn the rotary control to
select USBDEVICE. Press the Enter softkey and the instrument will list the
directories of the folders and files in the USB storage device. You can turn
the rotary control to select a folder or file. Press the Enter softkey to enter
the currently selected folder. To return to the parent directory, press the
Back softkey. After selecting the storage path, press the SaveAs softkey and
the input keyboard appears on the screen. Turn the rotary control to select
a character. Press the ABC/abc softkey to toggle the case of keyboard
characters. Press the Select softkey to enter the current character. Press the
Delete softkey to delete the last character that has been entered. Press the
Done softkey to finish editing and the waveform will be saved in the bin file
format under the current path.
File Store System (Store)
The storage location is divided into the internal storage (INTER) and the USB device
storage (USBDEVICE). When a USB device is connected, the main interface will show
"USBDEVICE" and "INTER". Otherwise, the main interface will show "INTER" only.
The internal memory can store 32 arbitrary waveform data.
Press the front panel Store function key to enter the file system.
Save the current arbitrary wave
(1) Press the Arbitrary Wave button to enter the Arbitrary Wave menu and
configure the waveform parameters.
(2) Press the front panel Store function key to enter the file system.
 If you want to save the current arbitrary waveform to the internal memory,
